Electromagnetic Lock 1200LBS 500KG Holding Force Electric Magnetic Door Lock 12V Fail Safe NC Mode for Access Control System
Product details
| Management number | 211284539 | Release Date | 2026/04/04 | List Price | $32.00 | Model Number | 211284539 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This 1200LBS Holding Force electric magnetic lock consists of an electromagnet and an armature plate used for access control door locks. By attaching this to the door frame and the armature plate to the door, a current passing through the electromagnet attracts the armature plate, holding the access control door lock shut. NC Mode (Fail-Safe Mode): The door will be closed when power is on; when power off, the door will open. It is suitable for wooden door, glass door, metal door, fire-proof door, Cabinet, etc. Specification: Electromagnetic plate Material: Aluminum Alloy + Metal Plate Armature Plate Material: Zinc Cover Finish: Anodized aluminum Color: Silver Holding Force: 1200LBS/500KG Input Voltage: DC 12V Operating Temperature: -10C to +55C (14 to 131F) Operating Current: 480mA Size: 10.43L x 2.95W x 1.54H (inch)/ 265L x 75W x 39H (mm) Armature plate: 7.28L x 2.36W x 0.51H (inch)/ 185L x 60W x 13H (mm) Package Weight: Approx. 9.5lb (4.27KG) Package list: 1 * Electromagnetic Lock 1 * Armature Plate 1 * Screws Pack 1 * User Manual (English)
- Materials: Stainless steel, Anti-residual magnesium designed. This magnetic door lock provides a strong sense of security with its outstanding holding force 1200Lbs (500KG) and significant features.
- Size: The lock size is 10.43 x 2.95 x 1.54 inch (265 x 75 x 39mm); Armature plate: 7.28 x 2.36 x 0.51 inch (185 x 60 x 13mm). Holding Force: 1200kg (500KG).
- Mode: NC Mode (Fail-Safe Mode), Locked whilst power supply is operating, unlocked when power off; Voltage: DC12V.
- Security protection: This electromagnetic lock has safety function. It is built in voltage spike suppressor.
- Wide Applications: This electric magnetic door lock is suitable for Wooden Door, Glass Door, Metal Door, Fire Proof Door, Cabinet, etc.
| UPC | 769894489826 |
|---|---|
| Color | 1200LBS Lock |
| Lock Type | Electromagnetic |
| Brand Name | YUANWIN |
| Style Name | Modern |
| Unit Count | 1.0 Count |
| Item Weight | 4.19 Kilograms |
| Finish Types | Polished |
| Manufacturer | YUANWIN |
| Model Number | Mag500KG |
| Material Type | Stainless Steel |
| Control Method | App |
| Item Type Name | Lock |
| Item Dimensions | 10 x 3 x 2 inches |
| Additional Features | Keyless |
| Included Components | Lock and Bracket |
| Recommended Uses For Product | Security |
| Manufacturer Warranty Description | 1 Year Warranty |
