AC Flush Kit Air Conditioning System Clean Canister with Real-time Monitoring Pressure Gauge & Relief Valve AC Flushing Tool Set for Air Conditioner Pipe, Condenser, Evaporator

Specifications: Material: Stainless Steel, Brass, Aluminum Operating Pressure: 1Mpa (10kgf/cm2) Gauge: 0-220psi, 0-16bar Connector Size: 1/4" Capacity: 1L Canister Height: 255mm / 10.0in Canister Diameter: 75mm / 3.0in Pipe Length: 3.5ft / 41.7in Canister Weight: 623g / 1.4lb Package Size: 347 x 154 x 89mm / 13.7 x 6.1 x 3.5in Package Weight: 1015g / 2.2lb How to Use: 1.Connect one end of the canister to the air pump,and the other end to the hose with sprayer, then check whether the sealing and accessories are normal 2.Pour the special cleaning solvent into the bottle and tighten the bottle cap 3.Turn on your air pump, and inflate about 8kg into the bottle (the product has a pressure relief valve,and the air pressure will automatically exhaust if the air pressure exceeds 15 kg) 4.Turn off the air pump and press the sprayer switch,the cleaning solvent will be sprayed from the nozzle under high pressure.Then you can start cleaning What You Get: 1 x Stainless Steel Canister (Empty) 1 x Pressure Gauge with 1/4" NPT American Air Plug and 1/4" SAE Hose Adapter 1 x Flush Head with Rubber Tapered Nozzle & 3.5FT Hose with 1/4" Female Brass Connector 1 x Spare 1/4" NPT European Air Plug 1 x Spare 1/4" SAE Brass Hose Adapter 1 x Spare Rubber Tapered Nozzle 1 x Spare Rubber O-rings of Cylinder Cap

• 32oz one-piece molding stainless steel canister, equipped with metal 1/4" NPT American air plug, built-in ball valve, brass bottle cap with rubber o-ring, metal hang hook, siphon tube, brass 1/4" SAE hose adapter, 220PSI pressure gauge. The flush can uses shop air to pressurize and spray specific AC flush solvent.
• Equipped with a pressure relief valve, you can adjust the pressure relief value according to your needs.
• Rubber nylon resin material durable hose, 3.5FT long, max working pressure is 600PSI and burst pressure is up to 3000PSI, each side is loaded with 1/4" female brass fittings for easy connection. Special small holes design on resin layer double ensure explosion-proof features of hose.
• Ergonomically designed flush tool body is made of aluminum, equipped with brass 1/4" SAE hose adapter, brass spray nozzle, rubber tapered tip. The rubber tapered tip can be sealed against pipe opening and prevent back spray of solution. If the pipe opening is smaller than the rubber tapered tip, you can try to take the tapered tip off and insert the brass spray nozzle into the pipe.
• Suitable for cleaning all air-conditioning systems and other systems, such as automobile AC pipes, condensers, evaporators, fuel pipes and household refrigerator/AC pipes.
